909007 - Dodge - TA9415H15M METRIC TAPER BUSH RED
Regular price
$45,772.53 USD
Same day shipping available on in stock items if ordered before 4pm EST. Expedited shipping available for in stock items. Please e-mail Sales@MRO-PT.com for expedited shipping.
Image for Illustration purposes only. Actual product may vary.
For shipping to Alaska or Hawaii please contact us. Shipping to Canada is available upon request.
This genuine Dodge component, identified by SKU 909041, is a twin-tapered bushing kit engineered for mounting a heavy-duty Dodge Torque-Arm II speed reducer on a short-length metric shaft. Specifically designed for the TA9415H reducer, this kit allows for a secure, concentric grip on a 95mm diameter shaft where the shaft does not extend fully through the reducer's hub. Constructed from high-strength ductile iron, this short shaft metric kit (MTBS) utilizes the patented Dodge twin-tapered system for an easy-on, easy-off fit that prevents fretting corrosion. This complete assembly is the ideal solution for reliable, damage-free shaft mounting in space-constrained, high-torque industrial applications.
TA9415H15M METRIC TAPER BUSH RED
Technical Specifications
| AGMA Size | 415 |
| Bore Length Output | 349.0000 |
| Bore Length Output (Unit) | MILLIMETER |
| Case Size | 9 |
| Depth | 551.0000 |
| Depth (Unit) | MILLIMETER |
| Gearbox Component Type | Gearbox |
| Housing Material | Cast Iron |
| Input Style | Solid Shaft |
| Input Shaft Diameter | 60.0000 |
| Input Shaft Diameter (Unit) | MILLIMETER |
| Maximum Speed Input | 1812 |
| Maximum Speed Input (Unit) | RPM |
| Output Orientation | Offset Parallel |
| Output Style | Hollow Bore,Screw Conveyor |
| Reduction Type | Double Stage |
| Seal Type | Two-Piece |
| Sheave Diameter Minimum | 274.0000 |
| Sheave Diameter Minimum (Unit) | MILLIMETER |
| Actual Ratio | 15.1 |
| Nominal Ratio | 15 |
