Image for Illustration purposes only. Actual product may vary.
For shipping to Alaska or Hawaii please contact us. Shipping to Canada is available upon request.
136160 - Dodge - NSTU-GTM-100
NSTU-GTM-100
Technical Specifications
| Ball Bearing Series | 206 Series |
| Bearing Type | Ball |
| Bore Length | 1.6100 |
| Bore Length (Unit) | INCH |
| CAD Link | https://dodge-embedded.partcommunity.com/3d-cad-models/?info=dodge/mounted_bearings/ball_bearings/standard/adapter_mount_grip_tight/inch/nstu_gtm_asmtab_i.prj&varset={SERIES=206},{SS=1},{PN=136160},{DESCRIPTION=NSTU-GTM-100},{PNSL=136212},{DESCRIPTIONSL=NSTU-GTU-06},{PNA=136541},{DESCRIPTIONA=AN-GTM-06-100-D},{W=2.8},{TUFS=NS308},{A=1.61},{B=4.31},{C=0.250},{D=2.50},{E=2.69},{F=3/4},{G=0.50},{H=0.94},{J=1.38},{L=2.08},{M=3.510/3.480},{N=4.13},{P=0.32},{R=0.52},{S=1.09},{Z=1.13},{CAPS=2250},{CAPD=4368}&hidePortlets=searchHeader |
| Dynamic Load Capacity | 4368 |
| Dynamic Load Capacity (Unit) | POUND_FORCE |
| Expansion Capability | Non-Expansion (Fixed) |
| Grease Name | Unirex N2 |
| Housing Construction | Solid |
| Housing Material | Cast Iron |
| Housing Type | Narrow-Slot Take-up |
| Insert Material | Steel |
| Lubrication | Grease |
| Maximum Speed | 7500 |
| Maximum Speed (Unit) | RPM |
| Seal Type | Single-Lip Contact |
| Sensor Ready | Adapter Required |
| Shaft Attachment | Push-Pull Adapter |
| Shaft Diameter | 1.0000 |
| Shaft Diameter (Unit) | INCH |
| Static Load Capacity | 2538 |
| Static Load Capacity (Unit) | POUND_FORCE |
| Take-Up Frame Size | NS-308 |
