TIGEAR-2 SPEED REDUCER-SPECIAL - Dodge
Regular price
$2,197.01 USD
Same day shipping available on in stock items if ordered before 4pm EST. Expedited shipping available for in stock items. Please e-mail Sales@MRO-PT.com for expedited shipping.
Image for Illustration purposes only. Actual product may vary.
For shipping to Alaska or Hawaii please contact us. Shipping to Canada is available upon request.
TIGEAR-2 SPEED REDUCER-SPECIAL
| Specifications | |
|---|---|
| Base to Output Center Height | 3.99 in |
| Case Size | 35 |
| Center Distance | 3.5 in |
| Gearbox Component Type | Gearbox |
| Horsepower Rating Input | 16.31 HP |
| Horsepower Rating Output | 15.48 HP |
| Housing Material | Cast Iron |
| Input Style | Solid Shaft |
| Input Shaft Diameter | 0.875 in |
| Input Shaft Length | 1.75 in |
| Lubrication | PAG, Standard Temperature |
| Mounting Bolt Pattern Length | 7.5 in |
| Mounting Bolt Pattern Width | 4 in |
| Output Shaft Location | Left |
| Output Style | Solid Shaft |
| Output Shaft Diameter | 1.5 in |
| Output Shaft Length | 3.51 in |
| Overhung Load | 2120 lbf |
| Paint Type | Stainless Epoxy |
| Rated Torque Output | 2787 in-lb |
| Seal Type | Two-Piece Harsh Duty |
| Suitable For Washdown | No |
| Thermal Horsepower Rating | 19.86 HP |
| Actual Ratio | 5 |
| Nominal Ratio | 5 |
