SS20Q40H56-1.0HPSS - Dodge - TIGEAR-2 REDUCER WITH MOTOR VFSWDM3546-E
Regular price
$4,757.60 USD
Same day shipping available on in stock items if ordered before 4pm EST. Expedited shipping available for in stock items. Please e-mail Sales@MRO-PT.com for expedited shipping.
Image for Illustration purposes only. Actual product may vary.
For shipping to Alaska or Hawaii please contact us. Shipping to Canada is available upon request.
TIGEAR-2 REDUCER WITH MOTOR VFSWDM3546-E
| Specifications | |
|---|---|
| Bore Diameter (Output) | 1.25 in |
| Bore Length | 5.7 in |
| Bushing Required | Optional |
| Case Size | 20 |
| Center Distance | 2 in |
| Gearbox Component Type | Gearbox |
| Horsepower Rating Input | 1.06 HP |
| Horsepower Rating Output | 0.79 HP |
| Housing Material | Stainless Steel |
| Input Connection Type | C-Face |
| Input Style | Direct Mount |
| Lubrication | PAG, Standard Temperature |
| Motor Compatibility | NEMA Motor, 56C Frame |
| Motor Connection | Quill |
| Motor Standard | NEMA |
| Output Orientation | Right-Angle |
| Output Style | Hollow |
| Rated Torque Output | 1125 in-lb |
| Seal Type | Two-Piece Harsh Duty |
| Suitable For Washdown | Yes |
| Thermal Horsepower Rating | 1.78 HP |
| Actual Ratio | 40 |
| Nominal Ratio | 40 |
