023254 - Dodge - F4B-K-315RE TYPE K
Regular price
$4,191.41 USD
Same day shipping available on in stock items if ordered before 4pm EST. Expedited shipping available for in stock items. Please e-mail Sales@MRO-PT.com for expedited shipping.
Image for Illustration purposes only. Actual product may vary.
For shipping to Alaska or Hawaii please contact us. Shipping to Canada is available upon request.
023254 - Dodge - F4B-K-315RE TYPE K
F4B-K-315RE TYPE K
Technical Specifications
| Bearing Type | Tapered Roller |
| Bolt Circle | 13.0000 |
| Bolt Circle (Unit) | INCH |
| Bolt Diameter | 1.0000 |
| Bolt Diameter (Unit) | INCH |
| Bolt to Bolt (Max) | 9.1900 |
| Bolt to Bolt (Max) (Unit) | INCH |
| Bolt to Bolt (Min) | 9.1900 |
| Bolt to Bolt (Min) (Unit) | INCH |
| Bore Length | 5.5000 |
| Bore Length (Unit) | INCH |
| CAD Link | https://dodge-embedded.partcommunity.com/3d-cad-models/?info=dodge/mounted_bearings/tapered_roller_bearings/type_k/f4b_flange_i_e_asmtab.prj&varset={SS=3-15/16},{PN=023254},{PNA=F4B-K-315RE},{WEIGHT=72},{A=5-1/2},{B=11-7/16},{C=4-5/8},{D=9-3/16},{E=1/8},{F=1},{G=12-7/8},{H=13/16},{J=9-3/16},{L=6-1/8},{T=6},{CS=154000},{CD=21000},{RN=26},{RM=.51},{PDI=5.120},{EP=.008-.012},{SC=5/8-11*1},{TC=1325},{MH=C.I. ASTM A48 CLASS 30},{MC=4118 CASE CARB.},{MCU=4118 CASE CARB.},{MR=STEEL},{MRO=4118 CASE CARB.},{SM=4.08}&hidePortlets=searchHeader |
| Dynamic Load Capacity | 24400 |
| Dynamic Load Capacity (Unit) | POUND_FORCE |
| Expansion Capability | Expansion (Float) |
| Grease Name | MobilGrease XHP222 |
| Housing Construction | Split |
| Housing Material | Ductile Iron |
| Housing Type | Four-Bolt Flange (Square) |
| Insert Material | Steel |
| Lubrication | Grease |
| Maximum Speed | 1530 |
| Maximum Speed (Unit) | RPM |
| Seal Type | Triple-Lip Contact |
| Sensor Ready | Adapter Required |
| Shaft Attachment | Setscrew |
| Shaft Diameter | 3.9375 |
| Shaft Diameter (Unit) | INCH |
| Static Load Capacity | 154000 |
| Static Load Capacity (Unit) | POUND_FORCE |
