023234 - Dodge - F4B-K-104RE TYPE K
Regular price
$702.56 USD
Same day shipping available on in stock items if ordered before 4pm EST. Expedited shipping available for in stock items. Please e-mail Sales@MRO-PT.com for expedited shipping.
Image for Illustration purposes only. Actual product may vary.
For shipping to Alaska or Hawaii please contact us. Shipping to Canada is available upon request.
023234 - Dodge - F4B-K-104RE TYPE K
F4B-K-104RE TYPE K
Technical Specifications
| Bearing Type | Tapered Roller |
| Bolt Circle | 5.6600 |
| Bolt Circle (Unit) | INCH |
| Bolt Diameter | 0.3750 |
| Bolt Diameter (Unit) | INCH |
| Bolt to Bolt (Max) | 4.0020 |
| Bolt to Bolt (Max) (Unit) | INCH |
| Bolt to Bolt (Min) | 4.0020 |
| Bolt to Bolt (Min) (Unit) | INCH |
| Bore Length | 2.5600 |
| Bore Length (Unit) | INCH |
| CAD Link | https://dodge-embedded.partcommunity.com/3d-cad-models/?info=dodge/mounted_bearings/tapered_roller_bearings/type_k/f4b_flange_i_e_asmtab.prj&varset={SS=1-1/4},{PN=023234},{PNA=F4B-K-104RE},{WEIGHT=6},{A=2-9/16},{B=5-3/16},{C=2-1/8},{D=4},{E=3/16},{F=3/8},{G=5-1/4},{H=7/16},{J=4},{L=2-1/4},{T=1/8},{CS=15760},{CD=2980},{RN=19},{RM=.23},{PDI=1.774},{EP=.004-.012},{SC=5/16-18*1/2},{TC=165},{MH=C.I. ASTM A48 CLASS 30},{MC=4118 CASE CARB.},{MCU=4118 CASE CARB.},{MR=STEEL},{MRO=4118 CASE CARB.},{SM=2.16}&hidePortlets=searchHeader |
| Dynamic Load Capacity | 3450 |
| Dynamic Load Capacity (Unit) | POUND_FORCE |
| Expansion Capability | Expansion (Float) |
| Grease Name | MobilGrease XHP222 |
| Housing Construction | Split |
| Housing Material | Ductile Iron |
| Housing Type | Four-Bolt Flange (Square) |
| Insert Material | Steel |
| Lubrication | Grease |
| Maximum Speed | 4490 |
| Maximum Speed (Unit) | RPM |
| Seal Type | Triple-Lip Contact |
| Sensor Ready | Adapter Required |
| Shaft Attachment | Setscrew |
| Shaft Diameter | 1.2500 |
| Shaft Diameter (Unit) | INCH |
| Static Load Capacity | 15760 |
| Static Load Capacity (Unit) | POUND_FORCE |
| Take-Up Frame Size | TS-300 |
